শান্ট,মিটার ব্রিজ ও হুইটস্টোন ব্রিজ

In a metre bridge experiment null point is obtained at 2020cm from one end of the wire when resistance X is balanced against another resistance Y. If X << Y, then where will be the new position of the null point from the same end, if one decides to balance a resistance of 4X4X against Y?

হানি নাটস

XY=2080=14 or Y=4X \frac{\mathrm{X}}{\mathrm{Y}}=\frac{20}{80}=\frac{1}{4} \text { or } \mathrm{Y}=4 \mathrm{X}

4XY=l100l \frac{4 \mathrm{X}}{\mathrm{Y}}=\frac{l}{100-l}

or

4X4X=l100l or l=50 cm \frac{4 \mathrm{X}}{4 \mathrm{X}}=\frac{l}{100-l} \text { or } \mathrm{l}=50 \mathrm{~cm}

শান্ট,মিটার ব্রিজ ও হুইটস্টোন ব্রিজ টপিকের ওপরে পরীক্ষা দাও
